Product Application


Medical

PEEK (PAEK) resin can be subjected to up to 3000 cycles of autoclaving at 140 ° C. The high temperature resistance of PEEK (PAEK) can be used to manufacture sterilization components, and it can be used for surgery requiring high re-use. And dental equipment. PEEK (PAEK) resin can maintain high mechanical strength, good stress resistance and hydrolytic stability under conditions of high temperature, high humidity, solvent and chemical reagents. It can be used to manufacture various medical instruments requiring high temperature steam sterilization. . More valuable is its non-toxic, light weight, corrosion resistance, etc., or the closest material to the human bones, can be combined with the body to replace the metal to make human bones, so using PEEK (PAEK) resin instead of metal to make human bones is It is another important application in the medical field.

Currently, PEEK (PAEK) materials related certifications and licenses

(1) Available materials recorded in the US Food and Drug Administration equipment and drug core documents

(2) Compliance with US Food and Drug Administration regulations

(3) Meet all requirements of the fourth category of the United States Pharmacopoeia

(4) Double proof of critical parameters of materials identified by NAMAS


Advantages of PEEK (PAEK) in medical materials

(1) Biocompatibility

(2) Excellent chemical resistance

(3) inherent lubricity

(4) Fatigue

(5) toughness and impact resistance

(6) Radiation translucency

(7) sterilizability

(8) Long-term stability

(9) Similar to the hardness of the bone


Aerospace

The replacement of metal materials or thermosetting composite materials by high-performance thermoplastic composite materials on large passenger aircraft has become a direction for the development of new materials and new technologies. Various developed countries and aviation organizations have increased research in this area. As the first thermoplastic material to be used in the aerospace industry, PEEK (PAEK) is now an integral part of aerospace materials. PEEK (PAEK) polymer materials are extremely robust, chemically inert and flame retardant, and easy to process. The advantages of components with extremely small tolerances have been officially approved by many aircraft manufacturers and are also in line with the requirements for the supply of military standard products.

A variety of new PEEK (PAEK) polymeric materials and composite grades currently available from Hengbo not only optimize mechanical properties, but also improve molding processability.

Main performance

High temperature and high

temperature

stability

Due to the semi-crystalline structure of PEEK (PAEK) polymer material, its mechanical properties are still good at temperatures above the glass transition temperature. Compared with other common high temperature thermoplastic materials, PEEK (PAEK) polymer materials High temperature resistance is more stable.

Flame retardancy

PEEK (PAEK) polymeric materials are also excellent in flame retardancy. PEEK (PAEK) has a flame retardant rating of UL94 V-0. The flame retardant properties are inherent to the material and do not require the addition of any flame retardant materials such as halogen additives. The data measured for the soot produced by the burning of plastic materials showed that PEEK (PAEK) polymeric materials had the lowest specific optical density values among all the tested materials.

Toxic

gas release

The amount of toxic gases produced by PEEK (PAEK) polymeric materials is minimal when burned. Its pyrolysis products are mainly carbon dioxide and carbon monoxide.

Thermal expansion coefficient

The addition of filler to the PEEK (PAEK) polymeric material reduces the coefficient of expansion to a level comparable to that of metal. Therefore, the metal component can be directly replaced by a polymeric material component without any problems caused by uneven expansion.

Strength

Compared to metals, PEEK (PAEK) polymeric materials have high tensile strength and low density. Reinforced with glass short fibers or carbon fibers, the strength-to-weight ratio is comparable or superior to that of conventional aerospace materials. Long fiber reinforced composites made of PEEK (PAEK) polymeric materials have significantly improved strength and rigidity.

Chemical resistance

PEEK (PAEK) polymeric materials have excellent chemical resistance and are resistant to a wide range of acids, bases and hydrocarbons including aviation fuels. When the PEEK (PAEK) composite was immersed in aviation hydraulic oil at 70 ° C for 1000 hours, its tensile strength, tensile modulus and tensile elongation decreased by less than 5%.


Car

In the context of environmental pollution, in order to achieve the purpose of reducing weight and energy saving, the use of traditional steel, iron, copper and other materials in automobiles has been gradually reduced, and the consumption of new lightweight materials has gradually increased. In particular, the development of plastic-based composite materials is very fast, playing an important role in the field of plastic-substituted steel.

Jiangsu Hengbo Composite Materials Co., Ltd. produces a variety of thermoplastic materials including PEEK (PAEK) polymeric materials. These high-performance thermoplastics maintain stable mechanical properties in high temperature environments above 140°C to meet the latest demands in the automotive industry. A recent study showed that PEEK (PAEK) polymeric materials can retain their original stiffness, tensile strength and impact strength after 5,000 hours of use: while traditional materials such as PPA and nylon have a performance degradation of up to 50 under the same conditions. %. PEEK (PAEK) thermoplastic polymer materials have a melting temperature above 340 ° C and a glass transition temperature above 140 ° C, which can adapt to harsh environments.

Main performance

High mechanical strength

PEEK (PAEK) polymeric materials maintain their mechanical properties well in working environments above their glass transition temperature.

Tensile fatigue performance

Hengbo's carbon fiber reinforced PEEK (PAEK) material is not only easy to process, but also has high mechanical properties and fatigue resistance.

Thermal expansion

Fillers added to PEEK (PAEK) polymeric materials can reduce the coefficient of thermal expansion (CTE) of materials to levels comparable to metals. Therefore, when a metal part is directly replaced with a polymeric material member, there is no risk at all due to the difference in expansion coefficient.

Tolerance

The tolerances of Hengbo's injection molded parts are usually within 0.05% of the specified size.

Specific strength

PEEK (PAEK) polymeric materials have high tensile strength and low density. Reinforcement with fiberglass or carbon fiber allows the strength-to-weight ratio of polymeric materials to meet or exceed common lightweight materials. The strength and rigidity of continuous fiber reinforced composites using PEEK (PAEK) polymeric matrix exceeds the strength and rigidity of some metallic materials.

Long-term stabilit

High performance thermoplastics such as PEEK (PAEK) polymeric materials with excellent long-term stability.

Structural strength

PEEK (PAEK) has the lowest weight per unit volume. PEEK (PAEK) replaces metal materials to reduce weight by up to 80%. PEEK (PAEK) outperforms standard aluminum alloys in terms of weight and profile thickness. Compared with ternary alloy brass materials, the size can be almost achieved. It's exactly the same.

Creep

Both filled and unfilled PEEK (PAEK) exhibited excellent creep resistance at room temperature. When the temperature exceeds the glass transition temperature (Tg), only enhanced PEEK (PAEK) is suitable for structural applications. The apparent modulus of PEEK (PAEK) is in many cases higher than the tensile/bending modulus of other high temperature resistant thermoplastics.

Friction

Hengbo PEEK (PAEK) and its composites have excellent wear resistance under high pressure and high speed conditions, and the wear grade PEEK (PAEK) has the best wear resistance.


Industry

PEEK (PAEK) resin has excellent mechanical, chemical and electrical properties and is suitable for harsh working environments such as high temperature, high pressure and high humidity. Because of these characteristics, PEEK (PAEK) resins are playing an increasingly important role in the industrial field. In the chemical industry and other processing industries, PEEK (PAEK) resin is commonly used to make compressor valve plates, piston rings, seals and various chemical pumps, valves and other components; using this material instead of stainless steel to make the impeller of the vortex pump, Significantly reduces wear and noise levels for a longer life.

Wire and cable and coil bobbins made of PEEK (PAEK) have been successfully applied to nuclear power plants, and can also be used for special geometries of petroleum exploration and mining machinery. In addition, modern connectors will be another potential application market because PEEK (PAEK) resins meet the specifications of the casing component materials and can be bonded using various adhesives at high temperatures. PEEK (PAEK) resin itself is highly pure and mechanically and chemically stable, which reduces contamination during wafer processing. When conveying ultrapure water, pipes, valves and pumps made of PEEK (PAEK) resin can make ultrapure water not polluted during transportation. In the semiconductor industry, PEEK (PAEK) resins are commonly used to fabricate wafer carriers, electronically insulating diaphragms, and various connection devices.

Main performance

High temperature resistance

PEEK (PAEK) can withstand continuous operating temperatures up to 260 ° C (PAEK can withstand up to 280 ° C), short-term use temperature up to 300 ° C, can win high temperature, high pressure working environment.

Wear resistance

PEEK (PAEK) and its composites have the best self-lubricating and wear-resistant properties in plastics.

Low coefficient of friction

The running resistance is small and there is no similar seizure between metal and metal parts.

Self-lubricating

In some specific cases no lubricant is required and the equipment can be cleaned.

Hydrolysis resistance

Long-term exposure to water and high-temperature and high-pressure steam maintains excellent mechanical properties and dimensional stability.

Chemical resistance

It can withstand acid and alkali, oil, grease and all other organic and inorganic solvents for a long time.

High mechanical strength

PEEK (PAEK) and its modified composites have the highest mechanical strength in plastics. Compressive and impact resistant, fatigue resistant.

Lighter than metal, the energy consumption is greatly reduced, and it is more wear resistant than copper alloy.

Dimensional stability

Filler grade materials reduce the thermal expansion coefficient. Increased heat distortion temperature ensures dimensional stability of the product.

Low outgassing

Reduces pollution and improves the reliability of fittings in applications where purity is required.

Low hygroscopicity

It is important to maintain dimensional stability and insulation properties.

It can be quickly formed, and it can be used for rapid injection molding of large-volume complex shaped parts by using injection molds, which is low in cost compared with machining.

Because PEEK (PAEK) has outstanding characteristics such as wear resistance, high temperature resistance, high strength and self-lubrication, it can ensure continuous long-term use on the equipment and avoid equipment downtime due to replacement parts.
